WIO A+ Server AS -1114S-WTRT

**WIO A Server AS-1114S-WTRT**
A high-performance, scalable server engineered for data-intensive workloads, featuring dual Intel Xeon Scalable processors, 12x 3.5″ hot-swap bays, and support for up to four GPUs. Optimized for AI, cloud, and enterprise applications, it delivers exceptional compute density, hybrid storage flexibility, and advanced thermal management for sustained reliability. Key benefits include energy efficiency, rapid deployment, and seamless scalability, while its unique edge lies in GPU-accelerated performance and enterprise-grade redundancy, ensuring minimal downtime and maximum ROI for demanding environments.

$Quote1 Piece(MOQ)

SKU AS -1114S-WTRT Categories , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • A+ ServerAS -1114S-WTRTStandard version with PWS-504P-1R (Platinum Level)
  • A+ ServerAS -1114S-WTRT-EUEuropean version with PWS-601A-1R (Titanium Level)

Motherboard

  • Super H12SSW-NT

Processor

  • CPU
    Single Socket SP3
    AMD EPYC 7002/7003 Series Processors

GPU

  • Max GPU Count
    Up to 2 double-width or 2 single-width GPUs
  • Supported GPU
    NVIDIA PCIe: T4, A2

System Memory

  • Memory
    Slot Count: 8 DIMM slots
    Max Memory (1DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM

On-Board Devices

  • Chipset
    System on Chip
  • Network Connectivity
    2 RJ45 10GbE
  • IPMI
    Support for Intelligent Platform Management Interface v.2.0
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
    2 RJ45 10 GBASE-T LAN ports
  • USB
    7 USB 3.0 ports
  • Video
    1 VGA port
  • DOM
    2 Super DOM (Disk on Module) ports

System BIOS

  • BIOS Type
    AMI 32MB SPI FLASH ROM

Management

  • Power configurations
    ACPI/APM Power Management

Chassis

  • Form Factor
    1U Rackmount
  • Model
    CSE-116TS-R504WBP

Dimensions and Weight

  • Height
    1.7″ (43 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    23.5″ (597 mm)
  • Package
    8″ (H) x 24″ (W) x 32″ (D)
  • Weight
    Gross Weight: 46 lbs (20.9 kg)
    Net Weight: 25 lbs (11.34 kg)
  • Available Color
    Black

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 2 PCIe 4.0 x16 FHFL slots 1 PCIe 4.0 x16 LP slot
  • M.2
    2 M.2 PCIe 3.0 x2 NVMe/SATA slots (M-key)

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 10 bays 10 front hot-swap 2.5″ SATA drive bays
    Option A: Total 10 bays 8 front hot-swap 2.5″ SATA drive bays 2 front hot-swap 2.5″ PCIe 3.0 NVMe* drive bays
    (*NVMe support may require additional storage controller and/or cables, please see the optional parts list for details)
  • M.2

System Cooling

  • Fans
    6 heavy duty fans with optimal fan speed control

Power Supply

  • 2x 500W
    2x 500W Redundant (1 + 1) Platinum Level (94%) power supplies
    Dimension (WxHxL)
    54.5 x 40.25 x 320 mm
    Total Output Power
    Input
    500W: 100-240Vac / 50-60Hz
    +12V
    Max: 42A / Min: 0.5A (100Vac-240Vac)
    Max: 42A / Min: 0.5A
    5V SB
    Max: 3A / Min: 0A
    Max: 4A / Min: 0A
    Output Type
    Backplanes (gold finger)
    Certification
    Platinum Level
    [
    Test Report
    ]
Brand

Supermicro
Products Status

New
Applications

Data Center Applications, DB Processing & Storage, Firewall Applications
Max GPU

1
CPU Type

AMD EPYC 7002/7003 Series Processors
Total PCI-E Slots

3
Drives

10
Drive Form Factors

2.5"
Form Factor

1U
Generation

H12
Interface

NVMe (Optional), SAS (Optional), SATA (Native)
Max GPU Count

Up to 2 double-width or 2 single-width GPUs
Supported GPU

A2View GPU Options, NVIDIA PCIe: T4
Network Connectivity

2 RJ45 10GbEView AOC Options
LAN

1 RJ45 1 GbE Dedicated BMC LAN port2 RJ45 10 GBASE-T LAN ports
BIOS Type

AMI 32MB SPI FLASH ROM
Package

8" (H) x 24" (W) x 32" (D)
Depth

23.5" (597 mm)
Fans

6 heavy duty fans with optimal fan speed control
Height

1.7" (43 mm)
M.2

2 M.2 PCIe 3.0 x2 NVMe/SATA slots (M-key)
Memory

Slot Count: 8 DIMM slotsMax Memory (1DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMMView Memory Options
Width

17.2" (437 mm)
Video

1 VGA port
ROHS

RoHS Compliant
Note

Supports up to 280W TDP CPUs (Air Cooled)
Weight

Gross Weight: 46 lbs (20.9 kg)Net Weight: 25 lbs (11.34 kg)
Drive Bays Configuration

Default: Total 10 baysOption A: Total 10 bays(*NVMe support may require additional storage controller and/or cables, please see the optional parts list for details)
USB

7 USB 3.0 ports
Available Color

Black
PCI-Express (PCIe) Configuration

Default
IPMI

Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
CPU

Single Socket SP3AMD EPYC 7002/7003 Series Processors
Chipset

System on Chip
Environmental Spec.
DOM

DOM
