Supermicro SYS-6019P-MTR

The Supermicro SYS-6019P-MTR is a high-density 1U rack server designed for enterprise and data center workloads, featuring dual Intel Xeon Scalable processors (up to 205W TDP) for robust performance. Key highlights include support for up to 3TB DDR4 memory, 10 hot-swap 2.5″ bays (mix of SAS3/SATA/NVMe), dual M.2 slots, and dual 10G LAN ports for high-speed connectivity. Optimized for virtualization, cloud computing, and storage-intensive tasks, it offers scalability, energy efficiency, and redundancy with 80+ Platinum PSUs. Unique selling points: compact yet powerful design, flexible storage/NVMe configurations, and advanced management tools (IPMI) for seamless remote monitoring—ideal for businesses prioritizing performance, density, and reliability in dynamic IT environments.

Read More

$Quote1 Piece(MOQ)

SKU SYS-6019P-MTR Categories , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:
Product SKUs

SYS-6019P-MTR
  • SuperServer 6019P-MTR (Black)

Motherboard


Super X11DPL-i

Processor/Cache

CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
    Dual UPI up to 10.4GT/s
  • Support CPU TDP 70-140W
Cores
  • Up to 28 Cores
Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

System Memory

Memory Capacity
  • 8 DIMM slots
  • Up to 2TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
Memory Type
  • 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro

On-Board Devices

Chipset
  • Intel® C621 chipset
SATA
  • SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers
  • Marvell 88E1512 PHY Gigabit Ethernet controller
  • Supports 1000BASE-T
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video
  • ASPEED AST2500 BMC

Input / Output

SATA
  • 4 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 2.0 ports (rear)
Video
  • 1 VGA port
Serial Port / Header
  • 1 COM port (header)
DOM
  • 2 SuperDOM (Disk on Module) ports

System BIOS

BIOS Type
  • 256Mb SPI Flash EEPROM with AMI BIOS

Management

Software
  • Intel® Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SSM, SPM, SUM
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI / APM Power Management

PC Health Monitoring

CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
