Supermicro MBD-X13SEFR-A

The Supermicro MBD-X13SEFR-A is an enterprise-grade ATX motherboard designed for Intel Xeon E-2400 processors, delivering robust performance for data centers, cloud infrastructure, and high-demand workloads. Key features include support for up to 128GB DDR5 ECC memory, PCIe 5.0 slots for ultra-fast storage and GPU expansion, dual 10G LAN ports for high-speed networking, and multiple storage options (SATA, M.2, U.2). Integrated IPMI 2.0 enables remote management, while TPM 2.0 enhances security. Its single-socket design optimizes power efficiency without compromising scalability. Benefits include exceptional reliability, future-proofed connectivity, and seamless integration into existing server ecosystems. Unique selling points: Combines cutting-edge PCIe 5.0 and DDR5 technologies with enterprise-grade redundancy and dual 10G LAN in a cost-effective, energy-efficient platform, ideal for AI/ML applications, virtualization, and storage-intensive tasks.

Read More

$Quote1 Piece(MOQ)

100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X13SEFR-A

Physical Stats

  • Form Factor
    Proprietary FatTwin
  • Dimension
    8.44″ x 18″ (21.44cm x 45.72cm)

Processor

  • CPU
    5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable processors
    Single Socket Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP
    *BIOS 2.1 or above is required to support 5th Gen Intel Xeon Scalable processors
  • Core
    Up to 64 cores

System Memory

  • Memory Capacity
    16 DIMM slots
    Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s
    **24GB & 48GB DIMM only support 1 DPC.
    *24GB/48GB/96GB DDR5 DIMMs with 24Gb chip are only supported by 5th and 4th XCC Gen Intel Xeon-SP CPU.
  • Memory Type
    5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4400MT/s (2DPC)
  • DIMM Sizes
    16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB
  • Memory Voltage
    1.1V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C741
  • SATA
    Intel C741 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Network Controllers
    AIOM for LAN

Input / Output

  • SATA
    10 SATA3 (6Gbps) port(s)
  • LAN
    1 RJ45 Dedicated IPMI LAN port
    AIOM
  • USB
    2 USB 3.2 Gen1 port(s) (2 rear)
  • Video Output
    VGA D-Sub Connector port(s)
  • Serial Port
    1 COM Port(s) (1 header)
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 5.0 x16 Right Riser Slot,
    1 PCIe 5.0 x16 AIOM
  • M.2
    M.2 Interface: 2 SATA/PCIe 3.0 x2
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.4
    SMBIOS 3.5
    UEFI 2.8 or above
BIOS Features ACPI 6.4SMBIOS 3.5UEFI 2.8 or above
TPM 1 TPM Header
Network Controllers AIOM for LAN
M.2 M.2 Interface: 2 SATA/PCIe 3.0 x2Form Factor: 2280/22110Key: M-Key
Chipset Intel C741
DIMM Sizes 128GB, 16GB, 24GB, 256GB, 32GB, 48GB, 64GB, 96GB
BIOS Type AMI UEFI
LAN 1 RJ45 Dedicated IPMI LAN portAIOM
Video Output VGA D-Sub Connector port(s)
Dimension 8.44" x 18" (21.44cm x 45.72cm)
PCIe 1 PCIe 5.0 x16 AIOM, 1 PCIe 5.0 x16 Right Riser Slot
USB 2 USB 3.2 Gen1 port(s) (2 rear)
Form Factor Proprietary FatTwin
Memory Type 5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4400MT/s (2DPC)
Application Server
IPMI ASPEED AST2600 BMC
Memory Voltage 1.1V
CPU 5th Gen Intel XeonSingle Socket Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP
Hardware Trusted Platform Module (TPM) 2.0
Serial Port 1 COM Port(s) (1 header)
SATA 10 SATA3 (6Gbps) port(s)
Memory Capacity 16 DIMM slotsUp to 4TB 3DS ECC RDIMM, DDR5-5600MT/s**24GB & 48GB DIMM only support 1 DPC.*24GB/48GB/96GB DDR5 DIMMs with 24Gb chip are only supported by 5th and 4th XCC Gen Intel Xeon-SP CPU.
Error Detection Corrects single-bit errors
Core Up to 64 cores
