Supermicro MBD-X13SEDW-F

**Supermicro MBD-X13SEDW-F**: Enterprise-grade motherboard designed for high-performance computing and data center applications. Features Intel Xeon E-2300 processor support, PCIe 4.0 (3x x8 slots), dual 10G LAN ports, and up to 128GB DDR4-3200 ECC memory. Offers extensive storage with 8 SATA3 ports and dual M.2 slots. Enhanced security via TPM 2.0 and remote management through IPMI 2.0 with KVM. Ideal for scalable, reliable, and secure enterprise workloads, combining cutting-edge connectivity, robust hardware encryption, and efficient remote administration.

$Quote1 Piece(MOQ)

SKU MBD-X13SEDW-F Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X13SEDW-F

Physical Stats

  • Form Factor
    Proprietary CloudDC
  • Dimension
    13″ x 13″ (33.02cm x 33.02cm)

Processor

  • CPU
    5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable processors
    Single Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP
    *BIOS 2.1 or above is required to support 5th Gen Intel Xeon Scalable processors
  • Core
    Up to 64 cores

System Memory

  • Memory Capacity
    16 DIMM slots
    Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s
    **24GB & 48GB DIMM only support 1 DPC.
    *24GB/48GB/96GB DDR5 DIMMs with 24Gb chip are only supported by 5th and 4th XCC Gen Intel Xeon-SP CPU.
  • Memory Type
    5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4400MT/s (2DPC)
  • DIMM Sizes
    16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB
  • Memory Voltage
    1.1V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C741
  • SATA
    Intel C741 controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 Aspeed AST2600 BMC port(s)
  • Network Controllers
    AIOM for LAN

Input / Output

  • SATA
    12 SATA3 (6Gbps) port(s)
  • LAN
    1 AIOM
    1 AIOM
  • USB
    2 USB 2.0 port(s) (2 via header)
    2 USB 3.2 Gen1 port(s) (2 rear)
  • Video Output
    1 VGA D-Sub Connector port(s)
  • Serial Port
    1 COM Port(s) (1 header)
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 5.0 x8 AIOM,
    1 PCIe 5.0 x0 AIOM,
    2 PCIe 5.0 x16 4C slots,
    8 PCIe 5.0 x4 PCIe5.0 MCIO connector,
    1 PCIe 5.0 x8 PCIe5.0 MCIO connector
  • M.2
    M.2 Interface: 2 PCIe 3.0 x2
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.4
    SMBIOS 3.5
    UEFI 2.8 or above
BIOS Features

ACPI 6.4SMBIOS 3.5UEFI 2.8 or above
Graphics

1 ASPEED AST2600 BMC port(s)
TPM

1 TPM Header
Network Controllers

AIOM for LAN
M.2

M.2 Interface: 2 PCIe 3.0 x2Form Factor: 2280/22110Key: M-Key
Chipset

Intel C741
DIMM Sizes

128GB, 16GB, 24GB, 256GB, 32GB, 48GB, 64GB, 96GB
BIOS Type

AMI UEFI
LAN

1 AIOM1 AIOM
Video Output

1 VGA D-Sub Connector port(s)
Dimension

13" x 13" (33.02cm x 33.02cm)
PCIe

1 PCIe 5.0 x0 AIOM, 1 PCIe 5.0 x8 AIOM, 1 PCIe 5.0 x8 PCIe5.0 MCIO connector, 2 PCIe 5.0 x16 4C slots, 8 PCIe 5.0 x4 PCIe5.0 MCIO connector
USB

2 USB 2.0 port(s) (2 via header)2 USB 3.2 Gen1 port(s) (2 rear)
Form Factor

Proprietary CloudDC
Memory Type

5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4400MT/s (2DPC)
Application

Server
IPMI

ASPEED AST2600 BMC
Memory Voltage

1.1V
CPU

5th Gen Intel XeonSingle Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP
Serial Port

1 COM Port(s) (1 header)
SATA

12 SATA3 (6Gbps) port(s)
Memory Capacity

16 DIMM slotsUp to 4TB 3DS ECC RDIMM, DDR5-5600MT/s**24GB & 48GB DIMM only support 1 DPC.*24GB/48GB/96GB DDR5 DIMMs with 24Gb chip are only supported by 5th and 4th XCC Gen Intel Xeon-SP CPU.
Error Detection

Corrects single-bit errors
Core

Up to 64 cores
