* NOTE: Image may not exactly match the product

Supermicro MBD-X13SCW-F

Designed for enterprise and data center applications, the Supermicro MBD-X13SCW-F supports Intel Xeon E-2300 and 12th Gen Core processors, delivering robust performance for demanding workloads. Key features include DDR4-3200 memory (up to 128GB), PCIe 4.0 slots for high-speed expansion, dual 10G LAN ports for ultra-fast networking, and versatile storage options (SATA3, M.2). Integrated ASpeed AST2600 BMC enables secure remote management, ideal for scalable IT infrastructure. Built for reliability and efficiency, it excels in cloud, AI, and virtualization environments. Combines cutting-edge connectivity, enterprise-grade management, and Supermicro’s proven durability for optimized server solutions.

Read More

$Quote1 Piece(MOQ)

SKU MBD-X13SCW-F Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X13SCW-F

Physical Stats

  • Form Factor
    Proprietary WIO
  • Dimension
    8″ x 13″ (20.32cm x 33.02cm)

Processor

  • CPU
    Intel Xeon E-2400/Pentium* Processor
    Single Socket V0 (LGA-1700) supported, CPU TDP supports Up to 95W TDP
    *Pentium G7400 and G7400T
  • Core
    Up to 8 cores

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC UDIMM, DDR5-4400MT/s
  • Memory Type
    4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (1DPC)
  • DIMM Sizes
    8GB, 16GB, 32GB
  • Memory Voltage
    1.1V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C266
  • SATA
    Intel C266 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 Aspeed AST2600 BMC port(s)
  • Network Controllers
    Dual LAN with 1GbE with Intel I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s) via Slimline SAS x8 connector
  • LAN
    2 RJ45 Gigabit Ethernet LAN ports
    1 RJ45 Dedicated IPMI LAN port
  • USB
    4 USB 2.0 port(s) (2 via header; 2 rear)
    2 USB 3.2 Gen1 port(s) (2 via header)
    3 USB 3.2 Gen2 port(s) (2 rear; 1 type A)
  • Video Output
    1 VGA D-Sub Connector port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 5.0 x16 Left Riser Slot,
    1 PCIe 4.0 x4 Right Riser (in x16) slot
  • M.2
    M.2 Interface: 2 PCIe 4.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI 32MB AMI UEFI
  • BIOS Features
    ACPI 6.4
    SMBIOS 3.5
    UEFI 2.8
    Plug and Play (PnP)
    PCI FW 3.3

Management

  • Power Configurations
    ACPI Power Management, Power-on mode control for AC power loss recovery, Power button override mechanism, Wake-On-LAN
BIOS Features ACPI 6.4SMBIOS 3.5UEFI 2.8Plug and Play (PnP)PCI FW 3.3
Graphics 1 ASPEED AST2600 BMC port(s)
TPM 1 TPM Header
Network Controllers Dual LAN with 1GbE with Intel I210
M.2 M.2 Interface: 2 PCIe 4.0 x4Form Factor: 2280/22110Key: M-Key
Chipset Intel C266
DIMM Sizes 16GB, 32GB, 8GB
BIOS Type AMI 32MB AMI UEFI
LAN 2 RJ45 Gigabit Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port
Video Output 1 VGA D-Sub Connector port(s)
Dimension 8" x 13" (20.32cm x 33.02cm)
PCIe 1 PCIe 4.0 x4 Right Riser (in x16) slot, 1 PCIe 5.0 x16 Left Riser Slot
USB 4 USB 2.0 port(s) (2 via header; 2 rear)2 USB 3.2 Gen1 port(s) (2 via header)3 USB 3.2 Gen2 port(s) (2 rear; 1 type A)
Form Factor Proprietary WIO
Memory Type 4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (1DPC)
Application Server
IPMI ASPEED AST2600 BMC
Memory Voltage 1.1V
CPU CPU TDP supports Up to 95W TDP, Intel Xeon E-2400/Pentium* ProcessorSingle Socket Socket V0 (LGA-1700) supported
Serial Port 2 COM Port(s) (1 header; 1 rear)
SATA 8 SATA3 (6Gbps) port(s) via Slimline SAS x8 connector
Memory Capacity 4 DIMM slotsUp to 128GB Unbuffered ECC UDIMM, DDR5-4400MT/s
Error Detection Corrects single-bit errorsDetects double-bit errors (using ECC memory)
Core Up to 8 cores
