Supermicro MBD-X13SCH-LN4F

**Supermicro MBD-X13SCH-LN4F: High-Performance Server Motherboard**
Built for demanding workloads, this motherboard supports Intel Xeon Scalable Processors (4th Gen) and the Intel C741 chipset, delivering enterprise-grade power. Features include 16 DDR5 DIMM slots (up to 4TB memory), PCIe 5.0 slots for ultra-fast GPUs/NVMe storage, dual 10G LAN ports, and extensive storage options (8x SATA, 3x M.2). Optimized thermal design ensures reliability, while integrated BMC enables remote management. Ideal for data centers, AI/ML, and cloud infrastructure, it combines scalability, cutting-edge connectivity, and server-grade redundancy for maximum uptime and performance.

$Quote1 Piece(MOQ)

SKU MBD-X13SCH-LN4F Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X13SCH-LN4F

Physical Stats

  • Form Factor
    microATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    Intel Xeon E-2400/Pentium* Processor
    Single Socket Socket V0 (LGA-1700) supported, CPU TDP supports Up to 95W TDP
    *Pentium G7400 and G7400T
  • Core
    Up to 8 cores

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC UDIMM, DDR5-4400MT/s
  • Memory Type
    4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (2DPC)
  • DIMM Sizes
    8GB, 16GB, 32GB
  • Memory Voltage
    1.1V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C266
  • SATA
    Intel C266 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 Aspeed AST2600 BMC port(s)
  • Network Controllers
    Quad LAN with 1GbE with Intel I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s) via Slimline SAS x8 connector
  • LAN
    4 RJ45 Gigabit Ethernet LAN ports
    1 RJ45 Dedicated IPMI LAN port
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
  • Video Output
    1 VGA D-Sub Connector port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 5.0 x16,
    2 PCIe 4.0 x4 (in x8 slot)
  • M.2
    M.2 Interface: 2 PCIe 4.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI 32MB AMI UEFI
  • BIOS Features
    ACPI 6.4
    SMBIOS 3.5
    UEFI 2.8
    Plug and Play (PnP)
    PCI FW 3.3

Management

  • Power Configurations
    ACPI Power Management, Power-on mode control for AC power loss recovery, Power button override mechanism, Wake-On-LAN
BIOS Features

ACPI 6.4SMBIOS 3.5UEFI 2.8Plug and Play (PnP)PCI FW 3.3
Graphics

1 ASPEED AST2600 BMC port(s)
TPM

1 TPM Header
Network Controllers

Quad LAN with 1GbE with Intel I210
M.2

M.2 Interface: 2 PCIe 4.0 x4Form Factor: 2280/22110Key: M-Key
Chipset

Intel C266
DIMM Sizes

16GB, 32GB, 8GB
BIOS Type

AMI 32MB AMI UEFI
LAN

4 RJ45 Gigabit Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port
Video Output

1 VGA D-Sub Connector port(s)
Dimension

9.6" x 9.6" (24.38cm x 24.38cm)
PCIe

1 PCIe 5.0 x16, 2 PCIe 4.0 x4 (in x8 slot)
USB

6 USB 2.0 port(s) (4 via header; 2 rear)5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
Form Factor

Micro-ATX
Memory Type

4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (2DPC)
Application

Server
IPMI

ASPEED AST2600 BMC
Memory Voltage

1.1V
CPU

CPU TDP supports Up to 95W TDP, Intel Xeon E-2400/Pentium* ProcessorSingle Socket Socket V0 (LGA-1700) supported
Hardware

Trusted Platform Module (TPM) 2.0
Serial Port

2 COM Port(s) (1 header; 1 rear)
SATA

8 SATA3 (6Gbps) port(s) via Slimline SAS x8 connector
Memory Capacity

4 DIMM slotsUp to 128GB Unbuffered ECC UDIMM, DDR5-4400MT/s
Error Detection

Corrects single-bit errorsDetects double-bit errors (using ECC memory)
Core

Up to 8 cores
