Supermicro MBD-X12STH-SYS

**Supermicro MBD-X12STH-SYS: Compact High-Performance Server System**
Built for Intel Xeon Scalable (Ice Lake-SP) processors, this 1U rackmount server delivers enterprise-grade power in a space-efficient design. Supports up to 1TB DDR4-3200 ECC memory, PCIe 4.0 expansion slots (including OCP 3.0), and flexible storage (NVMe/SATA). Features dual 10G LAN, IPMI remote management, and optimized thermal control for reliability in data centers, cloud, or edge environments. Combines scalability, energy efficiency, and Supermicro’s trusted durability for AI, HPC, and virtualization workloads.

$Quote1 Piece(MOQ)

SKU MBD-X12STH-SYS Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X12STH-SYS

Physical Stats

  • Form Factor
    Micro-ATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    10th Generation Intel Pentium Processor, Intel Xeon E-2300 Processor
    Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 95W TDP
  • Core
    Up to 8 cores, 16 threads

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
  • Memory Type
    3200/2933/2666 MT/s SDRAM
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C256
  • SATA
    Intel C256 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 ASPEED AST2600 BMC port(s)
  • Network Controllers
    Dual LAN with Intel Ethernet Controller I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s)
  • LAN
    2 RJ45 Gigabit Ethernet LAN ports
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 3.0 x4 (in x8 slot),
    1 PCIe 4.0 x16
  • M.2
    M.2 Interface: 1 PCIe 3.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    256MB UEFI
  • BIOS Features
    ACPI 6.0
    SMBIOS 2.7
    Plug and Play (PnP)
    RTC (Real Time Clock) Wakeup
    UEFI 2.7
    USB Keyboard support
    PCI 3.0

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
BIOS Features

ACPI 6.0SMBIOS 2.7Plug and Play (PnP)RTC (Real Time Clock) WakeupUEFI 2.7USB Keyboard supportPCI 3.0
Graphics

1 ASPEED AST2600 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with Intel Ethernet Controller I210
M.2

M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280/22110Key: M-Key
Chipset

Intel C256
DIMM Sizes

16GB, 32GB, 4GB, 8GB
BIOS Type

256MB UEFI
LAN

2 RJ45 Gigabit Ethernet LAN ports
Video Output

1 VGA port(s)
DOM

DOM
Dimension

9.6" x 9.6" (24.38cm x 24.38cm)
PCIe

1 PCIe 3.0 x4 (in x8 slot), 1 PCIe 4.0 x16
USB

6 USB 2.0 port(s) (4 via header; 2 rear)5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
Form Factor

Micro-ATX
Memory Type

3200/2933/2666 MT/s SDRAM
Application

Server
IPMI

ASPEED AST2600 BMC
Memory Voltage

1.2V
CPU

10th Generation Intel Pentium Processor, CPU TDP supports Up to 95W TDP, Intel Xeon E-2300 ProcessorSingle Socket LGA-1200 (Socket H5) supported
Serial Port

2 COM Port(s) (1 header; 1 rear)
SATA

8 SATA3 (6Gbps) port(s)
Memory Capacity

4 DIMM slotsUp to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
Error Detection

Corrects single-bit errors
Core

16 threads, Up to 8 cores
