* NOTE: Image may not exactly match the product

Supermicro MBD-X12STH-LN4F

Supermicro MBD-X12STH-LN4F is a high-performance server motherboard designed for data centers and enterprise workloads. It supports dual 3rd Gen Intel Xeon Scalable processors (Ice Lake-SP) with up to 40 cores each, 8-channel DDR4-3200 memory (16 DIMMs), and PCIe 4.0 expansion for ultra-fast data throughput. Features include quad 10Gbps LAN ports, multiple PCIe 4.0 x16 slots, SATA/NVMe storage options, and IPMI remote management. Ideal for AI, cloud, HPC, and virtualization, it delivers scalability, reliability, and energy efficiency with Supermicro’s optimized thermal design and robust security. USP: Combines cutting-edge PCIe 4.0, quad 10G networking, and enterprise-grade manageability for demanding workloads.

Read More

$Quote1 Piece(MOQ)

100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X12STH-LN4F

Physical Stats

  • Form Factor
    Micro-ATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    10th Generation Intel Pentium Processor, Intel Xeon E-2300 Processor
    Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 95W TDP
  • Core
    Up to 8 cores, 16 threads

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
  • Memory Type
    3200/2933/2666 MT/s SDRAM
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C256
  • SATA
    Intel C256 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 ASPEED AST2600 BMC port(s)
  • Network Controllers
    Quad LAN with Intel Ethernet Controller I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s)
  • LAN
    4 RJ45 Gigabit Ethernet LAN ports
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 3.0 x4 (in x8 slot),
    1 PCIe 4.0 x16,
    1 PCIe 4.0 x4 (in x8 slot)
  • M.2
    M.2 Interface: 1 PCIe 3.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    256MB UEFI
  • BIOS Features
    ACPI 6.0
    SMBIOS 2.7
    Plug and Play (PnP)
    RTC (Real Time Clock) Wakeup
    UEFI 2.7
    USB Keyboard support
    PCI 3.0

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
BIOS Features ACPI 6.0SMBIOS 2.7Plug and Play (PnP)RTC (Real Time Clock) WakeupUEFI 2.7USB Keyboard supportPCI 3.0
Graphics 1 ASPEED AST2600 BMC port(s)
TPM 1 TPM Header
Network Controllers Quad LAN with Intel Ethernet Controller I210
M.2 M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280/22110Key: M-Key
Chipset Intel C256
DIMM Sizes 16GB, 32GB, 4GB, 8GB
BIOS Type 256MB UEFI
LAN 4 RJ45 Gigabit Ethernet LAN ports
Video Output 1 VGA port(s)
DOM DOM
Dimension 9.6" x 9.6" (24.38cm x 24.38cm)
PCIe 1 PCIe 3.0 x4 (in x8 slot), 1 PCIe 4.0 x16, 1 PCIe 4.0 x4 (in x8 slot)
USB 6 USB 2.0 port(s) (4 via header; 2 rear)5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
Form Factor Micro-ATX
Memory Type 3200/2933/2666 MT/s SDRAM
Application Server
IPMI ASPEED AST2600 BMC
Memory Voltage 1.2V
CPU 10th Generation Intel Pentium Processor, CPU TDP supports Up to 95W TDP, Intel Xeon E-2300 ProcessorSingle Socket LGA-1200 (Socket H5) supported
Serial Port 2 COM Port(s) (1 header; 1 rear)
SATA 8 SATA3 (6Gbps) port(s)
Memory Capacity 4 DIMM slotsUp to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
Error Detection Corrects single-bit errors
Core 16 threads, Up to 8 cores
