* NOTE: Image may not exactly match the product

Supermicro MBD-X12SPT-GC

**Supermicro MBD-X12SPT-GC**
A high-performance dual-socket server motherboard designed for enterprise and data center workloads, featuring 3rd Gen Intel Xeon Scalable (Ice Lake-SP) processors for advanced compute power. Supports up to 16 DDR4-3200 DIMMs (4TB RAM), ensuring rapid data processing for memory-intensive tasks. Offers eight SATA ports, dual M.2 NVMe slots (PCIe 4.0), and seven PCIe 4.0 x16 slots for flexible storage and expansion. Integrated dual 10G Ethernet ports and optional OCP 3.0 support enable high-speed networking, while IPMI 2.0 ensures remote management efficiency. Built on the E-ATX form factor, it balances scalability and density, ideal for AI, cloud, virtualization, and HPC applications. Key benefits include enterprise-grade reliability, optimized thermal design, and future-proof PCIe 4.0 bandwidth. USP: Combines cutting-edge I/O throughput, robust expandability, and Supermicro’s industry-leading durability for mission-critical deployments.

$Quote1 Piece(MOQ)

SKU MBD-X12SPT-GC Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X12SPT-GC

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    8.53″ x 12.42″ (21.67cm x 31.55cm)

Processor

  • CPU
    3rd Gen Intel Xeon Scalable processors
    Single Socket Socket P+ (LGA-4189) supported, CPU TDP supports Up to 270W TDP
  • Core
    Up to 40 cores

System Memory

  • Memory Capacity
    16 DIMM slots
    Up to 2TB Intel Optane Persistent Memory 200 Series
    Up to 2TB ECC LRDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 2TB ECC RDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-3200MT/s
  • Memory Type
    3200/2933/2666 MT/s ECC , DDR4 LRDIMM, RDIMM
  • DIMM Sizes
    8GB, 16GB, 32GB, 64GB, 128GB, 256GB
    DCPMM: 64GB, 128GB, 256GB
    LRDIMM: 64GB, 128GB
    LRDIMM: 128GB, 256GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
    RDIMM: 64GB, 128GB, 256GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C621A
  • SAS
    Broadcom 3808 SAS3 (12 Gbps) controller for 6 SAS3 (6 Gbps) ports
  • Graphics
    1 ASPEED AST2600 BMC port(s)
  • Network Controllers

Input / Output

  • Serial Port
    1 COM Port(s) (1 header)
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
  • M.2
    M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1
    Form Factor: 2280
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
Graphics

1 ASPEED AST2600 BMC port(s)
TPM

1 TPM Header
M.2

M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1Form Factor: 2280Key: M-Key
Chipset

Intel C621A
DIMM Sizes

128GB, 128GBLRDIMM: 128GB, 16GB, 256GB, 256GBDCPMM: 64GB, 256GBLRDIMM: 64GB, 256GBRDIMM: 8GB, 32GB, 64GB, 64GBRDIMM: 64GB, 8GB
BIOS Type

AMI UEFI
Dimension

8.53" x 12.42" (21.67cm x 31.55cm)
Form Factor

Proprietary
Memory Type

3200/2933/2666 MT/s ECC, DDR4 LRDIMM, RDIMM
Application

Server
Memory Voltage

1.2V
CPU

3rd Gen Intel Xeon Scalable processorsSingle Socket Socket P+ (LGA-4189) supported, CPU TDP supports Up to 270W TDP
SAS

Broadcom 3808 SAS3 (12 Gbps) controller for 6 SAS3 (6 Gbps) ports
Hardware

Trusted Platform Module (TPM) 2.0
Serial Port

1 COM Port(s) (1 header)
Memory Capacity

16 DIMM slotsUp to 2TB Intel Optane Persistent Memory 200 SeriesUp to 2TB ECC LRDIMM, DDR4-3200MT/s, DDR4-3200MT/s; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-3200MT/s; Up to 2TB ECC RDIMM
Error Detection

Corrects single-bit errors
Core

Up to 40 cores
