Supermicro MBD-X12SPM-TF

: A compact, high-performance Micro-ATX motherboard designed for Intel Xeon W-1300 processors, featuring eight DDR4-3200 DIMM slots (up to 512GB RAM) for demanding workloads. Offers triple PCIe 4.0 x16 slots, triple M.2 NVMe, and eight SATA3 ports for versatile storage/expansion. Dual 10G LAN and IPMI 2.0 enable rapid data transfer and remote management. Ideal for SMBs, data centers, and creative workstations, its enterprise-grade build, thermal efficiency, and scalability excel in AI, virtualization, and media production. Combines power, flexibility, and reliability in a space-saving design.

Read More

$Quote1 Piece(MOQ)

SKU MBD-X12SPM-TF Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X12SPM-TF

Physical Stats

  • Form Factor
    microATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    3rd Gen Intel Xeon Scalable processors
    Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
  • Core
    Up to 40 cores

System Memory

  • Memory Capacity
    8 DIMM slots
    Up to 2TB Intel Optane Persistent Memory 200 Series
    Up to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-3200MT/s
  • Memory Type
    ECC , DDR4 LRDIMM (3DS), RDIMM (3DS)
  • DIMM Sizes
    LRDIMM 3DS: 128GB, 256GB
    LRDIMM: 64GB, 128GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C621A
  • SATA
    Intel C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 ASPEED AST2600 BMC port(s)
  • Network Controllers
    Dual LAN with 10GBase-T with Intel X550

Input / Output

  • SATA
    10 SATA3 (6Gbps) port(s)
  • LAN
    2 RJ45 10GBase-T ports
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    1 COM Port(s) (1 header)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    2 PCIe 4.0 x16,
    1 PCIe 4.0 x8,
    2 PCIe 4.0 x8 SimSAS connector
  • M.2
    M.2 Interface: 1 SATA/PCIe 3.0 x4
    Form Factor: 2280, 22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.0
    RTC (Real Time Clock) Wakeup
    SMBIOS 3.0 or later

Management

  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
BIOS Features ACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics 1 ASPEED AST2600 BMC port(s)
TPM 1 TPM Header
Network Controllers Dual LAN with 10GBase-T with Intel X550
M.2 22110Key: M-Key, M.2 Interface: 1 SATA/PCIe 3.0 x4Form Factor: 2280
Chipset Intel C621A
DIMM Sizes 128GBRDIMM: 8GB, 16GB, 256GBLRDIMM: 64GB, 32GB, 64GB, LRDIMM 3DS: 128GB
BIOS Type AMI UEFI
LAN 2 RJ45 10GBase-T ports
Video Output 1 VGA port(s)
DOM DOM
Dimension 9.6" x 9.6" (24.38cm x 24.38cm)
PCIe 1 PCIe 4.0 x8, 2 PCIe 4.0 x16, 2 PCIe 4.0 x8 SimSAS connector
USB 6 USB 2.0 port(s) (4 via header; 2 rear)5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
Form Factor Micro-ATX
Memory Type DDR4 LRDIMM (3DS), ECC, RDIMM (3DS)
Application Server
IPMI ASPEED AST2600 BMC
Memory Voltage 1.2V
CPU 3rd Gen Intel Xeon Scalable processorsSingle Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
Serial Port 1 COM Port(s) (1 header)
SATA 10 SATA3 (6Gbps) port(s)
Memory Capacity 8 DIMM slotsUp to 2TB Intel Optane Persistent Memory 200 SeriesUp to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM
Error Detection Corrects single-bit errors
Core Up to 40 cores
