| BIOS Features | ACPI 6.0SMBIOS 3.0 or laterPlug and Play (PnP) |
|---|---|
| Graphics | 1 ASPEED AST2500 BMC port(s) |
| TPM | 1 TPM Header |
| Network Controllers | Dual LAN with Intel i210 Gigabit Ethernet Controller |
| M.2 | M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280Key: M-Key |
| Chipset | Intel C422 |
| DIMM Sizes | 128GB, 16GB, 32GB, 4GB, 64GB, 8GB |
| BIOS Type | AMI UEFI |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports |
| Video Output | 1 VGA port(s) |
| DOM | DOM |
| Dimension | 9.6" x 9.6" (24.38cm x 24.38cm) |
| PCIe | 1 PCIe 3.0 x16, 2 PCIe 3.0 x8 |
| USB | 6 USB 2.0 port(s) (4 via header; 2 rear)3 USB 3.2 Gen1 port(s) (2 via header; 1 type A)2 USB 3.0 port(s) (2 rear) |
| Form Factor | Micro-ATX |
| Memory Type | 2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM, RDIMM |
| Application | Server |
| IPMI | ASPEED AST2500 |
| Memory Voltage | 1.2V |
| CPU | CPU TDP supports Up to 165W TDP, Intel Xeon W-2100 Processors, Intel Xeon W-2200 ProcessorsSingle Socket Socket R4 (LGA-2066) supported |
| Serial Port | 2 COM Port(s) (1 header; 1 rear) |
| SATA | 8 SATA3 (6Gbps) port(s) |
| Memory Capacity | 4 DIMM slotsUp to 512GB ECC LRDIMM, DDR4-2933MT/s, DDR4-2933MT/s; Up to 256GB ECC RDIMM |
| Error Detection | Corrects single-bit errors |
| Core | 36 threads, Up to 18 cores |
Supermicro MBD-X11SRM-VF-B
**Supermicro MBD-X11SRM-VF-B**: A high-performance server motherboard designed for enterprise and data center workloads. Features dual LGA 3647 sockets supporting Intel Xeon Scalable processors, 12 DDR4 DIMM slots (up to 1TB ECC memory), and Intel C422 chipset for robust scalability. Includes eight SATA3 ports, dual M.2 NVMe slots, three PCIe 3.0 x16, and one x8 slot for expansion. Dual 10G LAN ports (Intel X550-AT2) ensure ultra-fast networking, while IPMI 2.0 with KVM enables secure remote management. Compact Micro-ATX form factor optimizes space efficiency without sacrificing performance. Built with server-grade reliability, TPM support, and compatibility with demanding applications like virtualization, AI, and storage solutions. **USP**: Balances enterprise-grade power, scalability, and dense connectivity in a space-saving design, ideal for cloud, HPC, and storage environments.
