* NOTE: Image may not exactly match the product

Supermicro MBD-X11SPH-nCTPF

**Supermicro MBD-X11SPH-nCTPF**: A high-performance server motherboard built for enterprise and data center workloads. Features dual Intel Xeon Scalable Processors (LGA 3647), 16 DDR4 DIMM slots (up to 2TB ECC memory), and Intel C621 chipset for robust scalability. Includes PCIe 3.0 expansion (x16/x8 slots), dual 10G LAN via Intel X550 controllers, and NVMe/SATA storage support. Integrated IPMI 2.0 enables remote management, while optimized airflow and redundant power ensure reliability. Ideal for AI, virtualization, and HPC environments, its USP lies in balancing extreme compute density, energy efficiency, and enterprise-grade resilience in an E-ATX form factor.

$Quote1 Piece(MOQ)

SKU MBD-X11SPH-nCTPF Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-X11SPH-nCTPF

Physical Stats

  • Form Factor
    ATX
  • Dimension
    12″ x 9.6″ (30.48cm x 24.38cm)

Processor

  • CPU
    2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
    Single Socket Socket P (LGA-3647) supported, CPU TDP supports Up to 205W TDP
  • Core
    Up to 28 cores

System Memory

  • Memory Capacity
    8 DIMM slots
    Up to 2TB 3DS ECC LRDIMM, DDR4-2933MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-2933MT/s
  • Memory Type
    2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
  • DIMM Sizes
    LRDIMM: 32GB, 64GB, 128GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C622
  • SATA
    Broadcom 3008 SW controller for 8 SAS3 (12 Gbps) ports; RAID 0,1,10
    Intel C622 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 10G SFP+ with Intel X722 + Inphi CS4227

Input / Output

  • SATA
    10 SATA3 (6Gbps) port(s)
  • SAS
    8 SAS port(s)
  • LAN
    2 10G SFP+ LAN ports
  • USB
    8 USB 2.0 port(s) (2 rear; 6 via header)
    2 USB 3.0 port(s) (2 rear)
    3 USB 3 port(s) (2 via header; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 3.0 x16 (x16 or x8 ),
    1 PCIe 3.0 x8 (x0 or x8 ),
    1 PCIe 3.0 x8,
    1 PCIe 3.0 x4 (in x8 slot)
  • M.2
    M.2 Interface: PCIe 3.0 x4; SATA
    Form Factor: 2280
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.0
    RTC (Real Time Clock) Wakeup
    SMBIOS 3.0 or later

Management

  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
BIOS Features

ACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics

1 ASPEED AST2500 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with 10G SFP+ with Intel X722 + Inphi CS4227
M.2

M.2 Interface: PCIe 3.0 x4; SATAForm Factor: 2280Key: M-Key
Chipset

Intel C622
DIMM Sizes

128GBRDIMM: 8GB, 16GB, 32GB, 64GB, LRDIMM: 32GB
BIOS Type

AMI UEFI
LAN

2 10G SFP+ LAN ports
Video Output

1 VGA port(s)
DOM

DOM
Dimension

12" x 9.6" (30.48cm x 24.38cm)
PCIe

1 PCIe 3.0 x16 (x16 or x8 ), 1 PCIe 3.0 x4 (in x8 slot), 1 PCIe 3.0 x8, 1 PCIe 3.0 x8 (x0 or x8 )
USB

8 USB 2.0 port(s) (2 rear; 6 via header)2 USB 3.0 port(s) (2 rear)3 USB 3 port(s) (2 via header; 1 type A)
Form Factor

ATX
Memory Type

2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
Application

Server
IPMI

ASPEED AST2500
Memory Voltage

1.2V
CPU

2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable ProcessorsSingle Socket Socket P (LGA-3647) supported, CPU TDP supports Up to 205W TDP
SAS

8 SAS port(s)
Serial Port

2 COM Port(s) (1 header; 1 rear)
SATA

10 SATA3 (6Gbps) port(s)
Memory Capacity

8 DIMM slotsUp to 2TB 3DS ECC LRDIMM, DDR4-2933MT/s, DDR4-2933MT/s; Up to 2TB 3DS ECC RDIMM
Error Detection

Corrects single-bit errors
Core

Up to 28 cores
