| Graphics | 1 ASPEED AST2600 BMC port(s) |
|---|---|
| TPM | 1 TPM Header |
| Network Controllers | Dual LAN with 10GbE with Mellanox ConnectX-4 Lx EN, Or One(1) 25Gb port with the 2nd port being redundant/failover |
| M.2 | M.2 Interface: 1 PCIe 4.0 x4Form Factor: 2280/22110Key: M-Key |
| DIMM Sizes | 16GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI UEFI |
| Dimension | 12" x 13" (30.48cm x 33.02cm) |
| PCIe | 6 PCIe 4.0 x8 LP SlimSAS connector |
| USB | 4 USB 3 port(s) (2 via header; 2 Type A)1 USB 2 port(s) (1 via header) |
| Form Factor | Proprietary |
| Memory Type | 3200 MT/s ECC DDR4 LRDIMM, RDIMM |
| Application | Server |
| Memory Voltage | 1.2V |
| CPU | Ampere Altra and Ampere Altra MaxSingle Socket FCLGA-4926 supported, CPU TDP supports Up to 250W TDP |
| Serial Port | 1 COM Port(s) (1 Micro USB for COM (Debug)) |
| Memory Capacity | 16 DIMM slotsUp to 4TB ECC Registered LRDIMM, DDR4-3200MT/s, DDR4-3200MT/s; Up to 4TB ECC Registered RDIMM |
| Core | Up to 128 cores / 16MB Cache |
Supermicro MBD-R12SPD-R
The Supermicro MBD-R12SPD-R is a high-performance server motherboard designed for enterprise and data center applications. It supports Intel Xeon Scalable Processors (4th Gen) and DDR5 memory (up to 4TB), delivering exceptional compute power and speed. Key features include 8 PCIe 5.0 slots for high-speed expansion (GPUs, accelerators), 10x SATA + 4x M.2 NVMe storage options, and dual 10GbE LAN with OCP 3.0 support for scalable networking. Integrated BMC enables remote management, ensuring reliability and ease of maintenance. Ideal for AI, HPC, and cloud workloads, its PCIe 5.0 and DDR5 technologies offer future-proof scalability, while its robust design maximizes uptime and energy efficiency. USP: Unmatched versatility for demanding environments, combining cutting-edge performance with enterprise-grade reliability.
$Quote1 Piece(MOQ)
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:
Submit Inquiry
Buy more, save more. Contact us for exclusive discounts!
