| BIOS Features | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
|---|---|
| TPM | 1 TPM Header |
| Network Controllers | Dual LAN with Broadcom BCM5720 1GBase-T |
| M.2 | M.2 Interface: 2 SATA/PCIe 4.0 x4Form Factor: 2280/22110Key: M-Key |
| Chipset | System on Chip |
| DIMM Sizes | 128GB, 16GB, 192GB, 24GB, 256GB, 32GB, 384GB, 48GB, 64GB, 96GB |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| LAN | 1 RJ45 Dedicated IPMI LAN port |
| Video Output | 1 VGA port(s) |
| Dimension | 12" x 10.1" (30.48cm x 25.65cm) |
| PCIe | 2 PCIe 5.0 x8, 3 PCIe 5.0 x16 (in x16 slot) |
| USB | 6 USB 3.0 port(s) (4 USB; 2 via header) |
| Form Factor | ATX |
| Memory Type | 4800/6000 MT/s ECC DDR5 RDIMM (3DS) |
| Application | Server |
| Others | 1 MCIO (PCIe 5.0 x8/SATA3) Port(s)2 MCIO (PCIe 5.0 x8) Port(s) |
| Memory Voltage | 1.1V |
| CPU | AMD EPYC 9004/9005 Series Processors (*AMD EPYC 9005 series drop-in support requires board revision 2.x)Single Socket SP5 supported, CPU TDP supports Up to 400W TDP |
| Serial Port | 1 COM Port(s) (1 header) |
| SATA | 8 SATA3 (6Gbps) port(s) |
| Memory Capacity | 12 DIMM slotsUp to 4.5TB 3DS ECC Registered RDIMM, DDR5-6000MT/s |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Core | 320 threads, Up to 160 cores |
Supermicro MBD-H13SSL-N-B
**Supermicro MBD-H13SSL-N-B**: A high-performance server motherboard designed for AMD EPYC 9004 “Genoa” processors (SP5 socket), optimized for data centers, cloud, and HPC workloads. Features 24 DDR5 DIMM slots (up to 6TB memory), PCIe 5.0 expansion (128 lanes), dual 10G LAN, and 8x SATA/NVMe support. Integrated ASPEED AST2600 BMC enables secure remote management via IPMI. USP: Unmatched scalability, future-proof PCIe 5.0 bandwidth, and enterprise-grade reliability for AI, storage, and compute-intensive tasks.
