| BIOS Features | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
|---|---|
| Audio | ALC 888S HD Audio |
| TPM | 1 TPM Header |
| Network Controllers | Dedicated LAN for IPMI, Dual LAN with Intel i210 Gigabit Ethernet ControllerSingle LAN with ASPEED AST2600 BMC |
| M.2 | M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1Form Factor: 2280/22110Key: M-Key |
| Chipset | B650 |
| DIMM Sizes | 16GB, 24GB, 32GB, 48GB, 8GB |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Video Output | 1 DP 1.4a port(s), 1 HDMI 2.0 port(s), 2 rear type C port(s) DP 1.4 Alt mode |
| Dimension | 9.6" x 9.6" (24.384cm x 24.384cm) |
| PCIe | 1 PCIe 4.0 x4, 2 PCIe 5.0 x16 slots (16/NA or 8/8) |
| Form Factor | Micro-ATX |
| Memory Type | 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC) |
| Application | Server |
| IPMI | ASPEED AST2600 BMC |
| Memory Voltage | 1.1V |
| CPU | AMD EPYC 4004 series ProcessorsSingle Socket LGA-1718 (Socket AM5) supported, CPU TDP supports Up to 170W TDP |
| Serial Port | 1 COM Port(s) (1 header) |
| SATA | 1, 10, 4 SATA3 ports; RAID 0 |
| Memory Capacity | 4 DIMM slots |
| Core | 32 threads, Up to 16 cores |
Supermicro MBD-H13SAE-MF-B
**Supermicro MBD-H13SAE-MF-B: High-Performance Server Motherboard**
Designed for data centers and enterprise workloads, this ATX motherboard features AMD EPYC 8004 Series processors (SP6 socket) and 12 DDR5 DIMM slots for exceptional memory capacity and speed. Offers 8 SATA ports, 3 M.2 slots, and PCIe 5.0 expansion for scalable storage and high-bandwidth connectivity. Dual 10G LAN and IPMI remote management ensure robust networking and effortless system control. Built for reliability with ECC memory support, optimized thermal design, and energy efficiency. Ideal for cloud, storage, and HPC applications, it combines cutting-edge performance, future-proof scalability, and enterprise-grade durability in a compact form factor.
$Quote1 Piece(MOQ)
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Submit Inquiry
Buy more, save more. Contact us for exclusive discounts!
