| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 1 PCI-E 4.0 x32 Left Riser Slot1 PCI-E 4.0 x16 Right Riser Slot |
| Cores | Up to 64 Cores |
| Network Controllers | 2x 10GbE LAN Ports via Broadcom BCM574161 Realtek RTL8211E PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 SATA/PCI-E 4.0 x2Form Factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | 2 RJ45 10GBase-T LAN ports1 RJ45 Dedicated IPMI LAN port |
| NVMe | 2 NVMe (PCI-E Gen4) |
| USB | 1 Type A), 2 via header, 7 USB 3.0 ports (4 rear |
| Form Factor | Proprietary WIO |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2500 BMC |
| Others | 1 COM port2 SuperDOM power connectors1 TPM 1.2/2.0 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 16 SATA3 / 4 NVMe (PCI-E Gen4) |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7003/7002 Series ProcessorSocket SP3 |
| SATA | 2 SATA3 (6 Gbps) ports |
| Memory Capacity | 8 DIMM slotsSupports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 8.15" x 13.05" |
Supermicro MBD-H12SSW-NTL
**Supermicro MBD-H12SSW-NTL Server Motherboard**
Built for high-performance enterprise and data center workloads, this motherboard supports AMD EPYC 9004 Series CPUs (Zen 4 architecture) on the SP6 platform, delivering exceptional scalability and density. Key features include 12-channel DDR5 memory (24 DIMM slots, up to 6TB), 8x PCIe 5.0 slots for NVMe storage or GPUs, 8x SATA3 ports, 4x M.2 slots, and dual 10G LAN with IPMI remote management. Enhanced security via TPM 2.0 and secure boot ensures robust protection. Ideal for AI/ML, virtualization, and cloud applications, it combines cutting-edge PCIe 5.0 bandwidth, DDR5 efficiency, and Supermicro’s reliability for future-ready, high-density server solutions. **USP:** Unmatched performance scalability, advanced I/O flexibility, and enterprise-grade security in a single platform.
