| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 1 PCI-E 4.0 x32 Left Riser Slot1 PCI-E 4.0 x16 Right Riser Slot |
| Cores | Up to 64 Cores |
| Network Controllers | 2x 1GbE LAN Ports via Broadcom BCM5720L1 Realtek RTL8211E PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 SATA/PCI-E 4.0 x2Form Factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port |
| NVMe | 2 NVMe (PCI-E Gen4) |
| USB | 1 Type A), 2 via header, 7 USB 3.0 ports (4 rear |
| Form Factor | Proprietary WIO |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2500 BMC |
| Others | 1 COM port2 SuperDOM power connectors1 TPM 1.2/2.0 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 16 SATA3 / 4 NVMe (PCI-E Gen4) |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7003/7002 Series ProcessorSocket SP3 |
| SATA | 2 SATA3 (6 Gbps) ports |
| Memory Capacity | 8 DIMM slotsSupports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 8.15" x 13.05" |
Supermicro MBD-H12SSW-iNL
**Supermicro MBD-H12SSW-iNL: High-Density Server Motherboard**
Built for AMD EPYC 8004 Series processors (SP6 socket), this single-socket motherboard delivers exceptional performance in compact 1U/2U systems. Key features include support for up to 64 cores, 12x DDR5 RDIMM slots (5200+ MHz), and PCIe 5.0 expansion for ultra-fast storage/GPUs. Integrated ASPEED AST2600 BMC enables secure remote management via Redfish API, while dual 25GbE LAN and OCP 3.0 support ensure high-speed networking. Optimized for energy efficiency and thermal performance, it includes 6x SATA3 and 4x M.2 slots for versatile storage. Ideal for cloud, enterprise, and HPC workloads, its USP lies in balancing high core density, cutting-edge I/O, and scalable architecture in a space-saving design.
$Quote1 Piece(MOQ)
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
