| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 1 PCI-E 4.0 x16 Left Riser Slot1 PCI-E 4.0 x16 Right Riser Slot2 PCI-E 4.0 x16 slots for AIOM Networking |
| Cores | Up to 64 Cores |
| Network Controllers | Flexible networking provided via AIOM1 Realtek RTL8211F PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 PCI-E 4.0 x4Form Factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | 1 RJ45 Dedicated IPMI LAN port |
| NVMe | 12 NVMe (PCI-E Gen4) |
| USB | 2 USB 3.0 ports (rear)2 USB 2.0 ports via header |
| Form Factor | Proprietary |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2600 BMC |
| Others | 1 COM port1 TPM 1.2/2.0 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 8 SATA3 or 2 NVMe via single SlimSAS x88 SATA3 or 2 NVMe via dual SlimSAS x4 |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7003/7002 Series ProcessorSocket SP3 |
| SATA | SATA3 (6 Gbps) via SlimSAS |
| Memory Capacity | 16 DIMM slotsSupports up to 4TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 13.4" x 12.29" (34cm x 31.2cm) |
Supermicro MBD-H12SSW-AN6
**Supermicro MBD-H12SSW-AN6**: A single-socket server motherboard designed for AMD EPYC 8004 series processors (SP6 socket), optimized for cloud, edge, and data center workloads. Features 12 DDR5 DIMMs for high-speed memory scalability, PCIe 5.0 slots for ultra-fast connectivity, six SATA ports, three M.2 slots, and ASPEED AST2600 BMC for secure remote management. Delivers power efficiency, enterprise-grade reliability, and flexible storage/expansion options. Ideal for high-performance computing, storage, and scalable infrastructure deployments. USP: Combines next-gen AMD architecture with PCIe 5.0 and DDR5 support in a compact, management-ready platform.
$Quote1 Piece(MOQ)
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Q1: ls the product original ?
A1 : Yes, all of our products are orginal. We have our own QC team who will strictly check product quality before shipment.
Q2. Payment methods?
We accept T/T, PayPal, Alibaba ect.
Q3. Shipping methods?
We have long term business-ship with FedEx, UPS and DHL with favorble price. You can choose any shipping method mentioned above based on your ease. You can also use your own shipping account or shipping forwarder.
Q4. How long is the lead time?
Usually 1-3 working days after payment. Feel free to send me exact models for checking.
Q5. How long is the warranty period?
Different products have different warranty periods. Usually 1~3 years warranty.
