| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 5 PCI-E 4.0 x162 PCI-E 4.0 x8 |
| Cores | Up to 64 Cores |
| Network Controllers | Dual 10GBase-T LAN via Broadcom BCM574161 Realtek RTL8211F PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 PCI-E 4.0 x4Form Factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | Dual 10GBase-T LAN ports1 RJ45 Dedicated IPMI LAN port |
| USB | 6 USB 3.0 ports |
| Form Factor | ATX |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2500 BMC |
| Others | 1 COM port (rear)1 TPM 2.0 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 2 SlimSAS x8 ( |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7003/7002 Series ProcessorSocket SP3 |
| SATA | SATA3 (6 Gbps) |
| Memory Capacity | 8 DIMM slotsSupports up to 2TB Registered ECC DDR4 3200MHz SDRAM8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 12" x 9.6" (30.5cm x 24.4cm) |
Supermicro MBD-H12SSL-NT-O
**Supermicro MBD-H12SSL-NT-O: High-Performance Server Motherboard**
Built for AMD EPYC 9004 Series CPUs (SP5 socket), this motherboard delivers enterprise-grade performance with support for up to 2TB DDR5 ECC memory (16 DIMMs) and seven PCIe 5.0 x16 slots for unmatched scalability. Features include dual 10G LAN, eight SATA3 ports, dual M.2 slots, and IPMI 2.0 remote management for seamless administration. Ideal for cloud, AI/ML, and HPC workloads, it combines cutting-edge speed, massive expandability, and reliable out-of-band control in an ATX form factor. **USP:** Future-proof PCIe 5.0 and DDR5 integration with EPYC-driven power for data-intensive environments.
$Quote1 Piece(MOQ)
100% New and Genuine
