| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 6.2USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 3 PCI-E 4.0 x16 Riser Slots9 PCI-E 4.0 x8 SlimSAS2 PCI-E 4.0 x4 SlimSAS1 PCI-E 4.0 x16 AIOM LAN Networking Slot |
| Cores | Up to 64 Cores |
| Network Controllers | LAN Networking provided via AIOMDedicated IPMI via Realtek RTL8211F PHY |
| M.2 | 22110Key: M-Key, 2260, 2280, Interface: 2 PCI-E 4.0 x4Form Factor: 2242 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | Provided via AIOM1 RJ45 Dedicated IPMI LAN port |
| NVMe | 2 NVMe via SlimSAS |
| USB | 2 USB 3.0 ports (rear) |
| Form Factor | Proprietary |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2600 BMC |
| Others | 1 COM port (header)1 TPM 1.2/2.0 header |
| VGA | 1 VGA port (rear) |
| Memory Voltage | 1.2V |
| CPU | Single AMD Ryzen Threadripper PRO 5000WX/3000WX Series ProcessorSocket SP3 |
| Memory Capacity | 8 DIMM slotsSupports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 9.6" x 14.5" |
Supermicro MBD-H12SSG-ANP6
**Supermicro MBD-H12SSG-ANP6**: A high-performance single-socket SP6 motherboard built for AMD EPYC 8004 series processors, delivering scalable power for data centers and enterprise workloads. Supports up to 64 cores, 12 DDR5 DIMMs (2TB RAM), and PCIe 5.0 x16 slots for ultra-fast storage/GPU connectivity. Features dual 10G LAN, IPMI remote management, 8 SATA ports, and 3 M.2 slots. Optimized for energy efficiency, dense deployments, and cost-effective scalability in cloud, AI, and virtualization environments. Combines cutting-edge performance with future-proof expandability in a compact form factor.
