| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
|---|---|
| PCI-Express | 1 PCI-E 3.0 x32 Left Riser Slot1 PCI-E 3.0 x16 Right Riser Slot |
| Cores | Up to 32 CoresUp to 64 Cores (Board revision 2.x required) |
| Network Controllers | 2x 1GbE LAN Ports via Broadcom BCM5720L1 Realtek RTL8211E PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 PCI-E 3.0 x2Form factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 128Mb SPI Flash EEPROM |
| LAN | 2 RJ45 1GbE Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port |
| NVMe | 12 NVMe |
| USB | 7 USB 3.0 ports |
| Form Factor | Proprietary |
| Memory Type | 288-pin gold-plated DIMMs (Board revision 2.x required), 288-pin gold-plated DIMMsDDR4 3200 MHz Registered ECC, DDR4 2666 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2500 BMC |
| Others | 2 COM ports (rear)2 SATA DOM power connectors1 TPM 2.0 header1 TPM 1.2 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 16 SATA3 / 4 NVMe |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7001/7002Socket SP3 |
| SATA | 2 SATA3 (6 Gbps) ports |
| Memory Capacity | 16 DIMM slotsSupports up to 2TB Registered ECC DDR4 2666MHz SDRAM in 16 DIMMsSupports up to 4TB Registered ECC DDR4 3200MHz SDRAM (Board revision 2.x required)8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 13.4" x 12.29" (34cm x 31.2cm) |
Supermicro MBD-H11SSW-iN-B
Supermicro MBD-H11SSW-iN-B: A compact, high-performance server motherboard built for data-intensive workloads. Features AMD EPYC 3000 series processors (up to 32 cores), 4x DDR4 DIMMs (1TB max), dual 10G SFP+ ports, PCIe 3.0 expansion, and M.2/SATA storage. Mini-ITX form factor optimizes space efficiency without compromising power, ideal for edge computing, cloud, or storage solutions. Includes IPMI remote management, TPM security, and 80 Plus Platinum PSU support for reliability and energy savings. Combines enterprise-grade scalability, dense connectivity, and robust performance in a space-saving design.
