Supermicro MBD-B2SC2-TF

**Supermicro MBD-B2SC2-TF: High-Performance Server Motherboard**
Designed for enterprise and data center environments, the Supermicro MBD-B2SC2-TF delivers robust performance with support for dual Intel Xeon Scalable processors (2nd Gen) and up to 2TB DDR4 ECC memory across 16 DIMM slots. Features include 12 SATA3 ports, dual M.2 slots for NVMe storage, and seven PCIe 3.0 expansion slots for flexible scalability. Integrated dual 10Gbps LAN ports ensure high-speed networking, while IPMI 2.0 with dedicated LAN enables remote management. Optimized for cloud, virtualization, and storage-intensive workloads, it offers enterprise-grade reliability, energy efficiency, and a compact CEB form factor. Unique selling points include advanced thermal design, hardware-level security, and seamless integration into scalable server architectures, making it ideal for demanding applications requiring uptime, speed, and adaptability.

$Quote1 Piece(MOQ)

SKU MBD-B2SC2-TF Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-B2SC2-TF

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    4.8″ x 17″ (12.19cm x 43.18cm)

Processor

  • CPU
    Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor
    Dual Socket Socket H4 (LGA-1151) supported, CPU TDP supports Up to 95W TDP
  • Core
    Up to 8 cores

System Memory

  • Memory Capacity
    2 DIMM slots
    Up to 64GB ECC/non-ECC , DDR4-2666MT/s
    Up to 64GB ECC VLP UDIMM DDR4-2666Mhz support in 2 DIMM slots per node
  • Memory Type
    64GB DDR4-2666MHz in 4 DIMM slots
  • DIMM Sizes
    8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V

On-Board Devices

  • Chipset
    Intel C246
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 10Gbase-T, Two(2)10GbE Ethernet ports from KR interface to BP

Input / Output

  • DOM
    1 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header
  • Others
    1 SATA DOM and TPM header per node

Expansion Slots

  • PCIe
    2x U.2 (PCIex4 only) via backplane per node

System BIOS

  • BIOS Type
    128MB SPI Flash EEPROM with AMI BIOS
  • BIOS Features
    ACPI 6.1
    UEFI 2.7
    SMBIOS 2.8
    SMBIOS 3.1
    PCI FW 3.2
    Plug and Play (PnP)

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    +12V DC Power Input
BIOS Features

ACPI 6.1UEFI 2.7SMBIOS 2.8SMBIOS 3.1PCI FW 3.2Plug and Play (PnP)
Graphics

1 ASPEED AST2500 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with 10Gbase-T, Two(2)10GbE Ethernet ports from KR interface to BP
Chipset

Intel C246
DIMM Sizes

16GB, 32GB, 64GB, 8GB
BIOS Type

128MB SPI Flash EEPROM with AMI BIOS
DOM

DOM
Dimension

4.8" x 17" (12.19cm x 43.18cm)
PCIe

2x U.2 (PCIex4 only) via backplane per node
Form Factor

Proprietary
Memory Type

64GB DDR4-2666MHz in 4 DIMM slots
Application

Server
IPMI

ASPEED AST2500
Others

1 SATA DOM and TPM header per node
Memory Voltage

1.2V
CPU

CPU TDP supports Up to 95W TDP, Intel Xeon E-2100 Processor, Intel Xeon E-2200 ProcessorDual Socket Socket H4 (LGA-1151) supported
Memory Capacity

2 DIMM slotsUp to 64GB ECC/non-ECC, DDR4-2666MT/sUp to 64GB ECC VLP UDIMM DDR4-2666Mhz support in 2 DIMM slots per node
Core

Up to 8 cores
