Supermicro MBD-B2SC1-CPU

Supermicro MBD-B2SC1-CPU is a high-performance server motherboard designed for enterprise and data center applications. It supports dual Intel Xeon Scalable processors (1st/2nd Gen), delivering exceptional compute power for demanding workloads. Features include 16 DDR4 DIMM slots (up to 4TB ECC memory), eight SATA ports, dual 10G LAN, and multiple PCIe 3.0 slots for expandability. Integrated IPMI 2.0 enables remote management, while optimized thermal design ensures reliability. Ideal for virtualization, cloud, and storage solutions, it offers scalability, robust security (TPM), and energy efficiency. Its USP lies in Supermicro’s proven server architecture, balancing performance, flexibility, and enterprise-grade durability in a compact form factor.

$Quote5 pcs (MOQ) Minimum Order Quantity

SKU MBD-B2SC1-CPU Categories , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • MBD-B2SC1-CPU

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    4.8″ x 12.6″ (12.19cm x 32cm)

Processor

  • CPU
    Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor
    Single Socket Socket H4 (LGA-1151) supported, CPU TDP supports Up to 95W TDP

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MT/s
  • Memory Type
    2666/2400/2133/1866/1600 MT/s SDRAM 72-bit, 288-pin
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C246
  • SATA
    1 SATA3 (6 Gbps) ports
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 1GbE LAN via Intel i350-AM2

Input / Output

  • DOM
    1 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
  • M.2
    M.2 Interface: 1 SATA/PCIe 3.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    128MB SPI Flash EEPROM with UEFI BIOS
  • BIOS Features
    ACPI 6.1
    DMI (SMBIOS) 2.7
    UEFI 2.6

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
BIOS Features

ACPI 6.1DMI (SMBIOS) 2.7UEFI 2.6
Graphics

1 ASPEED AST2500 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with 1GbE LAN via Intel i350-AM2
M.2

M.2 Interface: 1 SATA/PCIe 3.0 x4Form Factor: 2280/22110Key: M-Key
Chipset

Intel C246
DIMM Sizes

16GB, 32GB, 4GB, 8GB
BIOS Type

128MB SPI Flash EEPROM with UEFI BIOS
DOM

DOM
Dimension

4.8" x 12.6" (12.19cm x 32cm)
Form Factor

Proprietary
Memory Type

2666/2400/2133/1866/1600 MT/s SDRAM 72-bit, 288-pin
Application

Server
IPMI

ASPEED AST2500
Memory Voltage

1.2V
CPU

CPU TDP supports Up to 95W TDP, Intel Xeon E-2100 Processor, Intel Xeon E-2200 ProcessorSingle Socket Socket H4 (LGA-1151) supported
SATA

1 SATA3 (6 Gbps) ports
Memory Capacity

4 DIMM slotsUp to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MT/s
Error Detection

Corrects single-bit errorsDetects double-bit errors (using ECC memory)
