| Brand | Intel |
|---|---|
| Products Status | New |
| Application | Server |
| CPU Socket Type | |
| Total Threads | 16 |
| Total Cores | 8 |
| Cache | 20 MB |
| TDP | 140 W |
| Manufacturing Tech | 14 nm |
| Processor Base Frequency | 3.40 GHz |
| Memory Types | DDR4 1600/1866/2133/2400 |
| Series | Intel Xeon E5 v4 |
| Part Number | E5-1680V4 |
| Model | CM8066002044401 |
| Hyper-Threading Support | Yes |
| Max Memory Size | 1.5 TB |
| Code Name | Broadwell |
| Max Turbo Frequency | 4.00 GHz |
| 64-Bit Support | Yes |
| Max # of Memory Channels | 4 |
| Max # of PCI Express Lanes | 40 |
| PCI Express Revision | 3 |
| Package Size | 45mm x 52.5mm |
| Embedded Options Available | No |
| Scalability | 1S Only |
| ECC Memory Supported | Yes |
| Max CPU Configuration | 1 |
| Instruction Set | 64-bit |
| PCI Express Configurations | x16, x4, x8 |
| Max Memory Bandwidth | 76.8 GB/s |
| Bus Speed | 0 GT/s |
| Physical Address Extensions | 46-bit |
Intel Xeon Server Processor E5-1680 v4 (20M Cache, 3.40 GHz)
The Intel Xeon E5-1680 v4 (20M Cache, 3.40 GHz) is an 8-core/16-thread server processor designed for high-performance computing, offering a base clock of 3.4 GHz and Turbo Boost up to 4.0 GHz. Its 20MB Smart Cache optimizes data-intensive workloads, while support for quad-channel DDR4-2400 memory enhances bandwidth for enterprise applications. Unique among Xeon processors, it features an unlocked multiplier for overclocking, enabling tailored performance gains. Built on 14nm architecture, it includes ECC memory support for reliability, Intel Hyper-Threading for multitasking efficiency, and advanced virtualization (VT-x/VT-d) and security (AES-NI) features. Ideal for demanding server environments, workstations, and HPC, it balances high clock speeds and multi-core power for tasks like virtualization, data analytics, and rendering.
