Intel Xeon E5-1620 V4 Broadwell-EP 3.5 GHz 4 x 256KB L2 Cache 10MB shared cache L3 Cache LGA 2011-3 140W BX80660E51620V4 Server Processor

**Intel Xeon E5-1620 V4 Processor Summary**
A high-performance server CPU designed for enterprise workloads, the Intel Xeon E5-1620 V4 features 4 cores, 8 threads, and a base clock of 3.5 GHz (turbo up to 3.8 GHz) for robust multitasking. Built on Broadwell-EP architecture with a 14nm process, it includes 4x256KB L2 and 10MB shared L3 cache for rapid data access. Supports LGA 2011-3 sockets, ECC memory, and virtualization (VT-x/VT-d), ensuring stability and efficiency in data-critical environments. With a 140W TDP, it balances power and performance for servers, workstations, and data centers. **Key USP**: Ideal for compute-intensive tasks, offering reliability, scalable performance, and backward compatibility with existing LGA 2011-3 systems.

$Quote1 Piece(MOQ)

SKU E5-1620v4 Categories , , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

With a software defined infrastructure and an agile cloud architecture, the Intel Xeon processor E5 family takes a leap in performance and capability. It provides agile services delivery for cloud and traditional applications and workloads with versatility across diverse workloads. It employs innovative technologies (like Intel TSX, Intel RD, etc.) to optimize workload performance, maximize security, and increase visibility and control over shared resources for improving utilization and delivering high-quality SLAs.

Memory Types

DDR4 1600/1866/2133/2400
Code Name

Broadwell
Max # of Memory Channels

4
TDP

140 W
Hyper-Threading Support

Yes
Model

CM8066002044103
Total Threads

8
Physical Address Extensions

46-bit
Manufacturing Tech

14 nm
PCI Express Revision

3
Max CPU Configuration

1
PCI Express Configurations

x16, x4, x8
Bus Speed

0 GT/s
ECC Memory Supported

Yes
Brand

Intel
Embedded Options Available

No
Processor Base Frequency

3.50 GHz
Scalability

1S Only
Max Turbo Frequency

3.80 GHz
64-Bit Support

Yes
Series

Intel Xeon E5 v4
Package Size

45mm x 52.5mm
Max # of PCI Express Lanes

40
Max Memory Bandwidth

76.8 GB/s
CPU Socket Type

Application

Server
Cache

10 MB
Part Number

E5-1620V4
Total Cores

4
Max Memory Size

1.5 TB
Products Status

New
Instruction Set

64-bit
