* NOTE: Image may not exactly match the product

Huawei S5700-10P-LI-AC(supports 8 10/100/1000BASE-T ports, 2 GE SFP ports, fixed DC power)

$Quote1 Piece(MOQ)

SKU S5700-10P-LI-AC Categories , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:
Weight (with packaging)

1.3 kg (2.87 lb)

Maximum power consumption (100% throughput)

11.5 W

Operating temperature

0C to 45C (32F to 113F) at an altitude of 0-1800 m (0-5906 ft.), NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1C (1.8F) every time the altitude increases by 220 m (722 ft.).

Products Status

New

Rated voltage range

100 V AC to 240 V AC, 50/60 Hz

Storage temperature

-40C to +70C (-40F to +158F)

Service port surge protection

Common mode: 6 kV

Power supply surge protection

6 kV in differential mode, 6 kV in common mode

PoE

Not supported

PN

2354036

Mean time to repair (MTTR)

2 hours

Memory (RAM)

256 MB

Availability

> 0.99999

Noise under normal temperature (27C, sound power)

Noise-free (no fans)

RPS

Not supported

Flash

200 MB

Relative humidity

5% to 95%, noncondensing

Operating altitude

0-5000 m (0-16404 ft.)

Model

S5700-10P-LI-AC

Dimensions (H x W x D)

43.6 mm x 250.0 mm x 180.0 mm (1.72 in. x 9.8 in. x 7.1 in.)

RTC

Not supported

Certification

EMC certification, Safety certification, Manufacturing certification

Mean time between failures (MTBF)

44.41 years

Wide [mm]

250.0mm

Stack ports

Not supported

Warranty

1 Year

Brand

Huawei

Height [mm]

43.6 mm

Maximum voltage range

90 V AC to 264 V AC, 47 Hz to 63 Hz

Typical power consumption (30% of traffic load) Tested according to ATIS standard EEE enabled No PoE power consumption

9.71 W

Depth [mm]

180.0mm

Q1: ls the product original ?

A1 : Yes, all of our products are orginal. We have our own QC team who will strictly check product quality before shipment.

Q2. Payment methods?

We accept T/T, PayPal, Alibaba ect.

Q3. Shipping methods?

We have long term business-ship with FedEx, UPS and DHL with favorble price. You can choose any shipping method mentioned above based on your ease. You can also use your own shipping account or shipping forwarder.

Q4. How long is the lead time?

Usually 1-3 working days after payment. Feel free to send me exact models for checking.

Q5. How long is the warranty period?

Different products have different warranty periods. Usually 1~3 years warranty.
