* NOTE: Image may not exactly match the product

HPE Aruba 6300F 24-port 1GbE Class 4 PoE and 4-port SFP56 Switch (JL666A)

**HPE Aruba 6300F 24-port 1GbE Class 4 PoE + 4-port SFP56 Switch (JL666A)**
A high-performance, scalable switch designed for modern enterprise networks, featuring 24×1GbE ports with Class 4 PoE (90W per port) to power high-demand devices like IoT sensors, cameras, and access points. Four SFP56 ports enable flexible 10/25GbE uplinks for high-speed aggregation. Built on Aruba’s AOS-CX operating system, it offers AI-driven insights, automated network optimization, and real-time analytics for simplified management. Advanced security includes dynamic segmentation and Zero Trust compliance. Stackable design and redundant power options ensure reliability and scalability. Ideal for bandwidth-intensive environments, it combines energy efficiency, robust PoE capabilities, and future-ready connectivity, backed by HPE’s lifetime warranty.

$Quote1 Piece(MOQ)

SKU JL666A Categories , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Key Features :

  • Device Type : Switch – 24 Ports – L3 – Managed – Stackable
  • Enclosure Type : Rack-mountable 1u
  • Subtype : Gigabit Ethernet
  • Ports : 24 X 10/100/1000 (poe+) + 4 X 50 Gigabit Ethernet Sfp56
  • Power Over Ethernet (poe) : Poe+
  • Poe Budget : 370 W
  • Performance : Switching Capacity: 448 Gbps | Switching Throughput: 334 Mpps | 1 Gbps Average Latency (64-byte Packets): 2.28 ??s | 10 Gbps Average Latency (64-byte Packets): 1.46 ??s | 25 Gbps Average Latency (64-byte Packets): 1.9 ??s | 50 Gbps Average Latency (64-byte Packets): 3.49 ??s | Stacking Bandwidth: 200 Gbps
  • Capacity : Switched Virtual Interfaces (svis): 1000 | Ipv4 Host Table Capacity: 32000 | Ipv6 Host Table Capacity: 32000 | Ipv4 Routes (unicast): 64000 | Ipv6 Routes (unicast): 32000 | Ipv4 Routes (multicast): 8000 | Ipv6 Routes (multicast): 8000 | Igmp Groups: 8000 | Mld Groups: 4000 | Ipv4 Acl Entries (ingress): 5000 | Ipv6 Acl Entries (ingress): 1250 | Mac Acl Entries (ingress): 5000 | Ipv4 Acl Entries (egress): 2000 | Ipv6 Acl Entries (egress): 500 | Mac Acl Entries (egress): 2000
  • Mac Address Table Size : 32000 Entries
  • Jumbo Frame Support : 9198 Bytes
  • Routing Protocol : Ospf, Bgp-4, Bgp, Igmp, Ospfv2, Pim-dm, Igmpv3, Msdp, Mldv2, Mld, Cidr
  • Remote Management Protocol : Snmp 1, Rmon, Telnet, Snmp 3, Snmp 2c, Http, Tftp, Ssh, Xrmon, Sftp
  • Encryption Algorithm : Ssl, Fips 140-2
  • Authentication Method : Secure Shell (ssh), Radius, Tacacs+
  • Features : Dhcp Support, Bootp Support, Arp Support, Vlan Support, Syslog Support, Port Mirroring, Diffserv Support, Ipv6 Support, Sflow, Virtual Route Redundancy Protocol (vrrp) Support, Multiple Spanning Tree Protocol (mstp) Support, Quality Of Service (qos), Mld Snooping, Trusted Platform Module (tpm), Front To Back Airflow, Uni-directional Link Detection (udld), Deficit Weighted Round Robin (dwrr), Lldp Support, Fan Tray, Snmp Trap, Management Information Base (mib), Virtual Routing And Forwarding (vrf), Multiple Vlan Registration Protocol (mvrp), Neighbor Discovery Protocol (ndp), Class Of Service (cos), Strict Priority (sp), Tagged Vlan, 8mb Packet Buffer, 802.1x Authentication, Type Of Service (tos), Bridge Protocol Data Unit (bpdu), Icmp Router Discovery Protocol (irdp), Virtual Extensible Lan (vxlan), Link Aggregation, Ethernet Virtual Private Network (evpn), Network Timing Protocol (ntp), Lldp-med, Denial Of Service (dos) Protection, Rapid Reconfiguration Of Spanning Tree (rstp), Cisco Discovery Protocol (cdp), Bootstrap Router (bsr) Mechanism
  • Compliant Standards : Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3af, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.3ae, Ieee 802.1s, Ieee 802.1t, Ieee 802.1v, Ieee 802.1ab (lldp), Ieee 802.1ak, Ieee 802.3an, Ieee 802.3at, Ieee 802.3ba, Ieee 802.1ax, Itu-t G.8032, Ieee 802.3bj, Ieee 802.3bm, Ieee 802.3by, Ieee 802.3bz, Ieee 802.3bt, Ieee 802.3cc, Itu-t Y.1344, Ieee 802.3cd
  • Processor : 1 X Arm Cortex-a72: 1.8 Ghz
  • Ram : 8 Gb Ddr4 Sdram
  • Flash Memory : 32 Gb

    Expansion / Connectivity :
    Interfaces :

  • 24 X 1000base-t Rj-45 Poe+ – 30 W
  • 4 X 50gbit Lan Sfp56
  • 1 X Console (usb) Type C
  • 1 X Usb Type A
Model

JL666A
Weight

9.61 lbs
Dimensions

Dimensions(H x W x D) = (1.73 x 17.4 x 12.9)
Brand

HPE
Features

JL666ASwitchL324 x 10/100/1000 (PoE+) + 4 x 50 Gigabit Ethernet SFP56PoE+managedrack-mountableInternal (fixed) power supply (200W)Dimensions(H x W x D) = (1.73 x 17.4 x 12.9)Weight = 9.61 lbs
