FusionServer 1288H V7

Brand	xfusion
Form Factor	1U
Other Features
Operating Temperature	5oC to 50oC (41oF to 122oF), compliant with ASHRAE Classes A1, A2, A3, and A4
OS	FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, openEuler
Network	Provides expansion capability of multiple types of networks, Supports OCP 3.0 NICs. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported
Fan Module	Provides 8 x hot-swappable counter-rotating fan modules in N+1 redundancy
RAID	RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
PCIe Expansion	Provides 5 x PCIe slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x PCIe slots, and 2 slots support PCIe 5.0
Security	Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
Management	The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management through the lifecycle
Certification	CE, UL, CCC, FCC, VCCI, and RoHS
Processor	1 or 2 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor
Memory	32 x DDR5 DIMMs, with up to 4800 MT/s speed
Installation Suite	L-shaped guide rails, adjustable guide rails, and holding rails
Power Supply	2 x hot-swappable PSUs in 1+1 redundancy mode. Supported options include: 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC), 1500 W AC Platinum PSUs, 1000 W (input: 100 V to 127 V AC), 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC), 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC), 1200 W C48 V to C60 V DC PSUs (input: C38.4 V to C72 V DC), 2000 W AC Platinum PSUs, 1800 W (input: 200 V to 220 V AC or 192 V to 200 V DC), 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)
Local Storage	Supports hot-swappable drives in the following configurations: 10 x 2.5 drives (6C10 NVMe SSDs and 0C4 SAS/SATA drives, with a total number of 10 or less), 10 x 2.5 SAS/SATA drives/SSDs (2C4 NVMe SSDs and 6C8 SAS/SATA drives, with a total number of 10 or less), 10 x 2.5 SAS/SATA drives/SSDs, 8 x 2.5 SAS/SATA drives/SSDs, 4 x 3.5 SAS/SATA drives/SSDs, 32 x E1.S SSDs, 20 x E3.S SSDs*, 2 x M.2 SSDs
Chipset	Emmitsburg PCH
