* NOTE: Image may not exactly match the product

WIO A+ Server AS -1115SV-WTNRT

**WIO A Server AS-1115SV-WTNRT**
A high-performance 1U rack server designed for enterprise and cloud environments, featuring an Intel Xeon Scalable processor for robust computing power. Key highlights include **16 hot-swappable drive bays** supporting SAS/SATA and NVMe storage for unmatched flexibility, **up to 2TB DDR4 memory** for intensive workloads, and **dual 10GbE LAN ports** ensuring high-speed connectivity. Built with **80+ Platinum redundant PSUs** for energy efficiency and uptime reliability, it excels in virtualization, big data, and AI applications. Its compact, scalable design and hybrid storage capabilities make it ideal for businesses prioritizing performance, adaptability, and future-proof infrastructure.

$Quote1 Piece(MOQ)

SKU AS -1115SV-WTNRT Categories , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • A+ ServerAS -1115SV-WTNRT

Motherboard

  • Super H13SVW-NT

Processor

  • CPU
    Single processor(s)
    AMD EPYC 8004 Series Processor
  • Core Count
    Up to 64C/128T

GPU

  • Max GPU Count
    Up to 1 double-width or 2 single-width GPUs
  • Supported GPU
    NVIDIA PCIe: L40, L4, A2

System Memory

  • Memory
    Slot Count: 6 DIMM slots
    Max Memory (1DPC): Up to 576GB 4800MT/s ECC DDR5 RDIMM

On-Board Devices

  • Chipset
    System on Chip
  • Network Connectivity
    2 RJ45 10GBASE-T with Broadcom BCM57416

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
    2 RJ45 10 GBASE-T LAN ports
  • USB
    2 ports(front)
    4 ports(rear)
  • Video
    1 VGA port
  • Serial
    1 COM port(Rear)
  • TPM
    1 TPM Onboard/port 80

System BIOS

  • BIOS Type
    AMI 32MB SPI Flash EEPROM
  • BIOS Features
    ACPI 6.4
    Plug and Play (PnP)
    SMBIOS 3.5 or later
    UEFI 2.8
    USB Keyboard support

Management

  • Power configurations
    1U redundant 800/860W Titanium AC power supply

Chassis

  • Form Factor
    1U
  • Model
    CSE-116BTS-R000WNP

Dimensions and Weight

  • Height
    1.7″ (43 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    23.5″ (597 mm)
  • Package
    7.75″ (H) x 23.5″ (W) x 31.5″ (D)
  • Weight
    Gross Weight: 33.5 lbs (15.2 kg)
    Net Weight: 21 lbs (9.53 kg)
  • Available Color
    Black

Front Panel

  • LED
    Fan Fail/System Over Heat LED
    HDD activity LED
    Network Activity LEDs
    Power status LED
  • Buttons
    Power On/Off button
    Unit Identification (UID) button

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 2 PCIe 5.0 x16 FHFL slots 1 PCIe 5.0 x16 LP slot
  • M.2
    2 M.2 PCIe 3.0 x4 NVMe slots (M-key)

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 10 bays 10 front hot-swap 2.5″ NVMe*/SAS*/SATA drive bays
    (*NVMe/SAS support may require additional storage controller and/or cables)
  • M.2
    2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280/22110)

System Cooling

  • Fans
    6 Heavy duty counter-rotating 40x40x56mm Fan(s)

Power Supply

  • 2x 860W
    2x 860W Redundant Titanium Level (96%) power supplies
    Dimension (WxHxL)
    54.5 x 40.25 x 322 mm
    Input
    800W: 100-127Vac / 50-60Hz
    860W: 200-240Vac / 50-60Hz
    860W: 240Vdc / 50-60Hz
    +12V
    Max: 66.67A / Min: 0A (100Vac-127Vac)
    Max: 71.67A / Min: 0A (200Vac-240Vac)
    Max: 71.67A / Min: 0A (Vdc-240Vdc)
    5V SB
    Max: 4A / Min: 0A
    Output Type
    Backplanes (gold finger)
Brand

Supermicro
Products Status

New
Applications

Data Center Optimized, Database/Storage, Edge/Cloud Computing Services, Firewall Applications, Virtualization
Max GPU

1
CPU Type

AMD EPYC 8004 Series Processor
Total PCI-E Slots

3
Drives

10
Drive Form Factors

2.5"
Form Factor

1U
Generation

H13
Interface

NVMe (Optional), SAS (Optional), SATA (Native)
LED

Fan Fail/System Over Heat LEDHDD activity LEDNetwork Activity LEDsPower status LED
Max GPU Count

Up to 1 double-width or 2 single-width GPUs
Serial

1 COM port(Rear)
Supported GPU

A2View GPU Options, L4, NVIDIA PCIe: L40
Network Connectivity

2 RJ45 10GBASE-T with Broadcom BCM57416View AOC Options
BIOS Features

ACPI 6.4Plug and Play (PnP)SMBIOS 3.5 or laterUEFI 2.8USB Keyboard support
LAN

1 RJ45 1 GbE Dedicated BMC LAN port2 RJ45 10 GBASE-T LAN ports
BIOS Type

AMI 32MB SPI Flash EEPROM
Package

7.75" (H) x 23.5" (W) x 31.5" (D)
Depth

23.5" (597 mm)
Fans

6 Heavy duty counter-rotating 40x40x56mm Fan(s)
Height

1.7" (43 mm)
Buttons

Power On/Off buttonUnit Identification (UID) button
M.2

2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280/22110)
Memory

Slot Count: 6 DIMM slotsMax Memory (1DPC): Up to 576GB 4800MT/s ECC DDR5 RDIMMView Memory Options
Width

17.2" (437 mm)
Video

1 VGA port
Core Count

Up to 64C/128T
Note

Supports up to 225W TDP CPUs (Air Cooled)
Weight

Gross Weight: 33.5 lbs (15.2 kg)Net Weight: 21 lbs (9.53 kg)
Drive Bays Configuration

Default: Total 10 bays(*NVMe/SAS support may require additional storage controller and/or cables)
USB

2 ports(front)4 ports(rear)
Available Color

Black
PCI-Express (PCIe) Configuration

Default
TPM

1 TPM Onboard/port 80
CPU

Single processor(s)AMD EPYC 8004 Series Processor
Chipset

System on Chip
Environmental Spec.
