* NOTE: Image may not exactly match the product

Ultra A+ Server AS -1024US-TRT (Complete System Only

**Ultra A Server AS-1024US-TRT (Complete System)**
A high-density, 1U rack server optimized for enterprise storage and data-intensive workloads. Features 24 hot-swappable drive bays (SAS/SATA/NVMe support), dual Intel Xeon Scalable processors, and up to 1TB DDR4 memory for unmatched performance. Built for scalability and reliability with redundant power supplies, advanced cooling, and PCIe 4.0 expansion. Ideal for hyperscale storage, AI/ML, and cloud infrastructure. Unique selling points: exceptional storage density in a compact form, energy-efficient design, and seamless integration with enterprise ecosystems. Benefits include reduced data center footprint, future-proof scalability, and 24/7 mission-critical uptime.

$Quote1 Piece(MOQ)

SKU AS -1024US-TRT Categories , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • A+ ServerAS -1024US-TRT

Motherboard

  • Super H12DSU-iN

Processor

  • CPU
    Dual Socket SP3
    AMD EPYC 7002/7003 Series Processors

GPU

  • Max GPU Count
    Up to 1 double-width or 1 single-width GPU
  • Supported GPU
    NVIDIA PCIe: T4, RTX A2000

System Memory

  • Memory
    Slot Count: 32 DIMM slots
    Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM

On-Board Devices

  • Chipset
    System on Chip
  • Network Connectivity
    2 RJ45 10GbE
  • IPMI
    Support for Intelligent Platform Management Interface v.2.0
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
  • USB
    3 USB 3.0 ports
  • Video
    1 VGA port
  • Serial
    1 COM port
  • DOM
    2 SATA DOM (Disk on Module) ports
  • TPM
    1 TPM header

System BIOS

  • BIOS Type
    AMI 128MB SPI Flash EEPROM
  • BIOS Features
    PCI 2.2
    Plug and Play (PnP)
    USB Keyboard support

Chassis

  • Form Factor
    1U Rackmount
  • Model
    CSE-819UTS-R1K02P-A

Dimensions and Weight

  • Height
    1.7″ (43 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    29″ (737 mm)
  • Package
    7.99″ (H) x 23.81″ (W) x 37.4″ (D)
  • Weight
    Gross Weight: 41 lbs (18.6 kg)
    Net Weight: 26 lbs (11.8 kg)
  • Available Color

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 1 PCIe 4.0 x16 LP slot 2 PCIe 4.0 x16 FH, 9.5″L slots 1 PCIe 4.0 x16 INTERNAL slot

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 4 bays 4 front hot-swap 3.5″ SATA drive bays
    Option A: Total 4 bays 4 front hot-swap 3.5″/2.5″ NVMe* drive bays
    Option B: Total 4 bays 4 front hot-swap 3.5″ SAS* drive bays
    (*NVMe/SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
  • M.2

System Cooling

  • Fans
    8 heavy duty fans with optimal fan speed control

Power Supply

  • 2x 1000W
    2x 1000W Redundant (1 + 1) Titanium Level (96%) power supplies
    Dimension (WxHxL)
    73.5 x 40 x 203 mm
    Input
    800W: 100-127Vac / 50-60Hz
    1000W: 200-240Vdc / 50-60Hz
    1000W: 200-240Vac / 50-60Hz
    +12V
    Max: 66.7A / Min: 0A (100Vac-127Vac)
    Max: 83A / Min: 0A (200Vac-240Vac)
    Max: 83A (200Vdc-240Vdc)
    12V SB
    Max: 2.1A / Min: 0A
    Output Type
    Backplanes (gold finger)
Brand

Supermicro
Products Status

New
Applications

Cloud Computing, High End Enterprise Server, Virtualization
Max GPU

2
CPU Type

AMD EPYC 7002/7003 Series Processors
Total PCI-E Slots

4
Drives

4
Drive Form Factors

3.5"
Form Factor

1U
Generation

H12
Interface

NVMe (Optional), SAS (Optional), SATA (Native)
Max GPU Count

Up to 1 double-width or 1 single-width GPU
Serial

1 COM port
Supported GPU

NVIDIA PCIe: T4, RTX A2000View GPU Options
Network Connectivity

2 RJ45 10GbEView Network Card (AOC) OptionsView AOC Options
BIOS Features

PCI 2.2Plug and Play (PnP)USB Keyboard support
LAN

1 RJ45 1 GbE Dedicated BMC LAN port
BIOS Type

AMI 128Mb SPI Flash EEPROM
Package

7.99" (H) x 23.81" (W) x 37.4" (D)
Depth

29" (737 mm)
Fans

8 heavy duty fans with optimal fan speed control
Height

1.7" (43 mm)
Memory

Slot Count: 32 DIMM slotsMax Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMMView Memory Options
Width

17.2" (437 mm)
Video

1 VGA port
ROHS

RoHS Compliant
Note

Supports up to 280W TDP CPUs (Air Cooled)
Weight

Gross Weight: 41 lbs (18.6 kg)Net Weight: 26 lbs (11.8 kg)
Drive Bays Configuration

Default: Total 4 baysOption A: Total 4 baysOption B: Total 4 bays(*NVMe/SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
USB

3 USB 3.0 ports
PCI-Express (PCIe) Configuration

Default
IPMI

Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
TPM

1 TPM Header
CPU

Dual Socket SP3AMD EPYC 7002/7003 Series Processors
Chipset

System on Chip
Environmental Spec.
DOM

DOM
