* NOTE: Image may not exactly match the product

Mainstream SuperServer SYS-620P-TRT

**Mainstream SuperServer SYS-620P-TRT**: A high-performance 2U rack server designed for data centers and enterprise workloads. Features dual Intel Xeon Scalable processors, support for up to 3TB DDR4 memory, 24x hot-swap drive bays (mix of SAS/SATA/NVMe), and 7x PCIe 4.0 slots for expansion. Redundant 1600W power supplies and advanced cooling ensure reliability and uptime. Optimized for virtualization, cloud, and storage-intensive tasks, it balances enterprise-grade power with cost efficiency, offering scalable flexibility and robust thermal management for demanding environments. Ideal for businesses seeking performance, scalability, and value without compromising on redundancy or future-proofing.

$Quote1 Piece(MOQ)

SKU SYS-620P-TRT Categories , , , , Brand:
100% New and Genuine
Million Models In St
Bulk Order Rebate
Fast Delivery
Payment:
Shipping:

Product SKUs

  • SuperServerSYS-620P-TRT

Motherboard

  • Super X12DPi-NT6

Processor

  • CPU
    Dual Socket P+ (LGA-4189)
    3rd Gen Intel Xeon Scalable processors
  • Core Count
    Up to 36C/72T; Up to 60MB Cache per CPU

System Memory

  • Memory
    Slot Count: 16 DIMM slots
    Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
    Supports Intel Optane persistent memory 200 series

On-Board Devices

  • Chipset
    Intel C621A
  • Network Connectivity
    2 RJ45 10GbE

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
  • USB
    2 USB 2.0 ports(front)
    4 USB 3.0 ports(rear)
  • Video
    1 VGA port
  • DOM
    2 Super DOM (Disk on Module) ports

System BIOS

  • BIOS Type
    AMI 32MB SPI Flash EEPROM

Management

  • Power configurations
    ACPI/APM Power Management

Chassis

  • Form Factor
    2U Rackmount
  • Model
    CSE-825BTS-R1K23LPP1

Dimensions and Weight

  • Height
    3.5″ (89 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    25.5″ (647 mm)
  • Package
    11.4″ (H) x 26.7″ (W) x 34.5″ (D)
  • Weight
    Gross Weight: 69 lbs (31.2 kg)
    Net Weight: 36.38 lbs (16.5 kg)
  • Available Color
    Black

Front Panel

  • LED
    HDD activity
    Network activity
    Power status
    System information (overheat/UID)
  • Buttons
    Power On/Off
    System Reset

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 2 PCIe 4.0 x8 LP slots 4 PCIe 4.0 x16 LP slots

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 8 bays 8 front hot-swap 3.5″ SAS*/SATA drive bays
    Option A: Total 10 bays 8 front hot-swap 3.5″ SAS*/SATA drive bays 2 front fixed 3.5″ NVMe*/SATA* drive bays
    (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details)
  • M.2
    1 M.2 NVMe slot (M-key)
  • Peripheral Bays
    1 slim DVD bay (optional)

System Cooling

  • Fans
    3 heavy duty fans with optimal fan speed control

Power Supply

  • 2x 1200W
    2x 1200W Redundant Titanium Level (96%) Hot-plug power supplies
    Dimension (WxHxL)
    76 x 40 x 336 mm
    Input
    1000W: 100-127Vac
    1000W: 100-127Vac / 50-60Hz
    1200W: 200-240Vac
    1200W: 200-240Vac / 50-60Hz
    1200W: 200-240Vdc / 50-60Hz (for CCC only)
    +12V
    Max: 83A / Min: 0A (100Vac-127Vac)
    Max: 100A / Min: 0A (200Vdc-240Vdc)
    Max: 100A / Min: 0A (200Vac-240Vac)
    5V SB
    Max: 4A / Min: 0A
    Output Type
    Backplanes (gold finger)
Brand

Supermicro
Products Status

New
Applications

Application and data serving, Compute Intensive Applications, Data Center Optimized, Enterprise Server, Model analysis, Virtualization
Max GPU

2
CPU Type

3rd Gen Intel Xeon Scalable processors
Total PCI-E Slots

6
Drives

8
Drive Form Factors

3.5"
Form Factor

2U
Generation

X12
Interface

NVMe (Optional), SATA (Native)
LED

HDD activityNetwork activityPower statusSystem information (overheat/UID)
Network Connectivity

2 RJ45 10GbEView AOC Options
LAN

1 RJ45 1 GbE Dedicated BMC LAN port
BIOS Type

AMI 32MB SPI Flash EEPROM
Package

11.4" (H) x 26.7" (W) x 34.5" (D)
Depth

25.5" (647 mm)
Fans

3 heavy duty fans with optimal fan speed control
Height

3.5" (89 mm)
Buttons

Power On/OffSystem Reset
Peripheral Bays

1 slim DVD bay (optional)
M.2

1 M.2 NVMe slot (M-key)
Memory

Slot Count: 16 DIMM slotsMax Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMMSupports Intel Optane persistent memory 200 seriesView Memory Options
Width

17.2" (437 mm)
Video

1 VGA port
ROHS

RoHS Compliant
Core Count

Up to 36C/72T; Up to 60MB Cache per CPU
Note

Supports up to 270W TDP CPUs (Air Cooled)
Weight

Gross Weight: 69 lbs (31.2 kg)Net Weight: 36.38 lbs (16.5 kg)
Drive Bays Configuration

Default: Total 8 baysOption A: Total 10 bays(*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details)
USB

2 USB 2.0 ports(front)4 USB 3.0 ports(rear)
Available Color

Black
PCI-Express (PCIe) Configuration

Default
CPU

Dual Socket P+ (LGA-4189)3rd Gen Intel Xeon Scalable processors
Chipset

Intel C621A
DOM

DOM
